All Specifications

Display

Brightness (ANSI lumens): 3600
Native Resolution: XGA (1024x768)
Native Aspect Ratio: 4:3
Contrast Ratio (FOFO): 20000:1
Display Color: 30 Bits (1,07 billion colors)
Light Source: Lamp
Light Source Life: Economic 10000 hrs, LampSave 15000 hrs, Normal 5000 hrs, SmartEco 10000 hrs

Optical

Throw Ratio: 1.96~2.15
Zoom Ratio: 1.1x
Lens: F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm
Projection Offset (Full-Height): 110%
Keystone Adjustment: 1D, Vertical ± 30 degrees

I/O Interface

PC in (D-sub 15pin): 1
Monitor out (D-sub 15pin): 1
Composite Video in (RCA): 1
S-Video in (Mini DIN 4pin): 1
HDMI in: 2, HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4)
USB Type Mini B: 1
RS232 in (DB-9pin): 1


Picture Modes: 3D, Bright, Infographic, Presentation, sRGB, User 1, User 2

Audio

Audio in (3.5mm Mini Jack): 1

Audio out (3.5mm Mini Jack): 1

Environment

Operating Temperature: 0~40℃
Power Supply: AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V): ~270W
Acoustic Noise (Typ./Eco.)(dB): 33/29

Accessories

Carry Bag: Yes,5J.J3T09.001 (optioN/Al)
Remote Control w/ Battery: RCX014
Power Cord (by region): 1 (1.8M)
VGA(D-sub 15pin) Cable: (Standard), 1 (1.5m)
User Manual CD: 1 (24L)
3D Glasses: (Optional), Yes, DGD5
Quick Start Guide: 1 (18L)
Warranty Card (by region): Yes
Universal Ceiling Mount: (Optional), Yes, CMG3

Projection System

Projection System: DLP

Connectivity

A. HDMI*2
B. PC-1
C. RS-232
D. USB Mini-B

experience-pure-clarity-with-finest--rystal-glasses-02

Notes

*Lamp in this product contains mercury.

To dispose of the product or used lamps, consult your local environment authorities for regulations or see www.lamprecycle.org.‎

*Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specifications are subject to change without notice..‎

**Offset is calucated by full screen height.
